1. Pre-Assembly Inspection

– Check for surface defects (scratches, plating damage) and dimensional consistency before use.

– Verify that the male pin diameter matches the socket inner diameter to ensure a tight, reliable fit.

2. Wire Connection (Crimping/Soldering)

– Crimping: Insert the stripped wire into the hollow socket, aligning it with the side hole. Use a precision crimping tool to compress the socket around the wire, creating a secure mechanical and electrical bond.

– Soldering (Optional)**: Apply low-temperature solder (≤260℃) through the side hole to attach the wire, avoiding overheating that could damage the gold plating. Clean residual flux after soldering.

3. Assembly into Connector Housing

– Align the step section of the pin/socket with the corresponding groove in the connector housing.

– Gently press the pin/socket into the housing until the step locks into place, ensuring it cannot move axially.

– Avoid excessive force to prevent deformation of the pin/socket or damage to the housing.

4. Mating & Disconnection

– Align the male pin with the female socket and insert smoothly to avoid bending the pin tip.

– Ensure full mating to guarantee optimal electrical contact.

– Pull straight back when disconnecting to avoid side stress that could damage the pin or socket.

5. Storage & Environmental Notes

– Store in a dry, dust-free environment (15–30℃, humidity ≤60%RH) to prevent gold plating oxidation.

– Avoid exposure to corrosive gases, acids, or alkalis to maintain conductivity and appearance.

6. Safety Precautions

– Wear anti-static gloves during handling to prevent ESD damage to sensitive electronic components.

– Do not exceed the rated current/voltage to avoid overheating, insulation breakdown, or electrical failure.
