KRX03

1. Pre-Assembly Preparation：

Inspect for surface defects (scratches, plating damage, deformation) and ensure male/female size matching.

Verify pin/socket size matches the connector housing hole to avoid assembly issues.

Prepare tools: precision crimping tool, low-temperature solder (≤260℃), anti-static gloves, cleaning cloth.

2.Crimping (Recommended)：

Strip wire insulation (2~3mm) without damaging conductors.

Insert stripped wire into the hollow female socket, aligning with the side hole.

Use a precision crimping tool to compress the socket, ensuring a tight bond (avoid over-crimping).

3.Soldering (Optional)：

Insert stripped wire into the socket’s side hole.

Use low-temperature solder (≤260℃) to secure the connection; wipe residual flux after soldering.

4.Assembly into Connector Housing：

Align the pin/socket’s step section with the housing groove.

Gently press until it locks into place (listen for a “click”)—do not use excessive force.

5.Mating & Disconnection：

Mating: Align male pin with female socket, insert smoothly for full contact.

Disconnection: Pull straight back—avoid side stress to prevent pin bending.

6.Storage & Maintenance：

Store in dry, dust-free environment; avoid corrosive gases/acids.

Regularly inspect for plating damage or loose connections; replace defective parts promptly.

7.Safety Precautions：

Wear anti-static gloves to prevent ESD damage to sensitive components.

Do not exceed rated current/voltage to avoid overheating or failure.

Keep away from children; avoid ingestion or improper handling.
